HOWO Truck Spare Parts – Complete EPC Catalog

Full-range spare parts for SINOTRUK HOWO heavy-duty trucks. Covering WD615 engine, HW19710 transmission, mid & rear axles, front axle, and complete cabin assembly. 1,800+ OEM part numbers across 67 sub-assemblies with factory cross-reference matching. Three quality tiers: Genuine OEM, OEM-Grade, and Aftermarket. Global export to Africa, Middle East, South America, Southeast Asia, and Europe.

Contact Us for Pricing

Interested in this product? Contact us now for detailed pricing and product information.

Product Details

Spare Parts Catalog
SINOTRUK HOWO — WD615 / HW19710 Series
HOWO Truck Spare Parts — Complete EPC Catalog

Full-range spare parts for SINOTRUK HOWO heavy-duty trucks. Covering WD615 engine, HW19710 transmission, mid & rear axles, front axle, and complete cabin assembly. 1,800+ OEM part numbers across 67 sub-assemblies with factory cross-reference matching. Three quality tiers available — Genuine OEM, OEM-Grade, and Aftermarket. Contact us for bulk quotation.

SINOTRUK HOWO
WD615 Engine
HW19710 Transmission
Genuine / OEM / Aftermarket
Global Export

1,800+
Part Numbers
5
Major Systems
67
Sub-Assemblies
3
Quality Tiers
100%
Pre-Ship Inspection

Catalog Systems Overview

This complete HOWO spare parts catalog is organized into five major systems, each broken down into detailed sub-assemblies with OEM part numbers, quantities, and specifications. Whether you’re maintaining a single truck or managing a fleet, you’ll find every component you need.

⚙
Engine (WD615)
~416 Parts
16 Sub-Assemblies
🔧
Transmission (HW19710)
~387 Parts
16 Sub-Assemblies
🛣
Mid & Rear Axle
~346 Parts
6 Sub-Assemblies
🚚
Front Axle
~98 Parts
2 Sub-Assemblies
🚪
Cabin Assembly
~625 Parts
27 Sub-Assemblies

1. WD615 Engine System (~416 Parts, 16 Sub-Assemblies)

The WD615 series is the workhorse engine platform for HOWO heavy trucks. Our catalog covers all 16 sub-assemblies from cylinder block to oil sump, with genuine SINOTRUK part numbers for exact matching.

1.1 Cylinder Block (Sub-Assembly 1 of 3)
Part No. Qty Part Name Specification
61500010383 1 Cylinder block assembly Complete assembly
61500010356B 1 Cylinder block Bare block
61500010366C 1 Crankcase –
VG1540010006 6 Cylinder liner –
VG1560010029 6 Camshaft bush –
VG1500010046 7 Main sleeve bearings Set
61557010008 1 Timing gearcase –
AZ1500010012 1 Flywheel housing –
1.2 Crankshaft, Piston & Cylinder Head
Part No. Qty Part Name Specification
61500020038 1 Crankshaft assembly –
61500030025 6 Piston assembly –
61500030026 6 Connecting rod –
61500040023 1 Cylinder head assembly –
61500040036 6 Intake valve –
61500040037 6 Exhaust valve –
61500050050 1 Valve rocker arm shaft –
61500060025 1 Water pump assembly –
1.3 Cooling, Lubrication, Fuel & Electrical
Part No. Qty Part Name Specification
61500080015 1 Oil pump assembly –
61500090048 1 Oil filter assembly –
61500100043 1 Fuel injection pump –
61500110035 1 Alternator assembly –
61500120028 1 Starter motor –
61500130022 1 Intake manifold –
61500140018 1 Exhaust manifold –
61500150012 1 Air compressor assembly Twin-cylinder

Above tables show representative parts. Full engine catalog includes 16 sub-assemblies: Cylinder Block (x3), Crankshaft & Flywheel, Piston & Connecting Rod, Cylinder Head, Valve Train, Cooling System, Oil Pump, Oil Filter, Fuel System, Electrical System, Intake System, Exhaust System, Air Compressor, and Oil Sump.

2. HW19710 Transmission System (~387 Parts, 16 Sub-Assemblies)

The HW19710 is a 16-speed heavy-duty transmission used across HOWO truck models. Our catalog covers all 16 sub-assemblies including the automatic range-shift and split-shift components.

2.1 Transmission Housing & Input Shaft
Part No. Qty Part Name Specification
AZ2203000001 1 Front housing assembly –
AZ2220000001 1 Front housing Bare housing
WG2229003030 1 Composite bush DX 30x34x30
AZ9003073001 1 Oil seal PS 30x45x8
AZ2203010003 1 Middle housing assembly –
AZ2203020007 1 Input shaft & gear assembly –
AZ2210020111 1 Input shaft Bare shaft
AZ2203020112 1 Drive gear (low range) –
2.2 Main Shaft, Countershaft & Gear Components
Part No. Qty Part Name Specification
AZ2203030001 1 Countershaft assembly –
AZ2203040001 1 Main shaft assembly –
AZ2203050001 1 Idler shaft assembly –
AZ2203060001 1 Transmission brake assembly –
AZ2203070001 1 Range sub-box assembly Auto range-shift
AZ2203090001 1 Shift fork shaft assembly –
AZ2203100001 1 Split-shift assembly Auto split-shift
AZ2203110001 1 Oil pump & piping assembly –

Full transmission catalog includes: Front Housing, Middle Housing, Input Shaft, Countershaft, Main Shaft, Idler Shaft, Brake, Range Sub-box, Cover, Shift Fork Shaft, Split-shift, Oil Pump & Piping, Pneumatic Valves, Clutch Control, Electrical Switches, and Nameplates.

3. Mid & Rear Axle System (~346 Parts, 6 Sub-Assemblies)

HOWO trucks use a three-piece cast axle housing design. Our catalog covers the mid-axle housing, rear axle housing, drive assemblies, hubs, and brake systems — including ABS variants.

3.1 Mid Axle Housing & Drive
Part No. Qty Part Name Specification
AZ9231330990 1 First axle housing (3-piece cast) Complete assembly
WG9231330015 1 Magnet plug –
WG9231330105 1 Breather –
WG9014320120 1 Main reducer housing (mid axle) –
AZ9231320272 1 Differential housing –
AZ9231320150 1 Differential spider –
WG9231320151 2 Bevel pinion (side gear) –
WG9231320152 4 Planet pinion –
3.2 Rear Axle Drive, Hub & Brake
Part No. Qty Part Name Specification
199112340029 2 Planetary carrier assembly –
WG9012340004 10 Planetary gear shaft –
WG9231340001 2 Hub cover –
WG9114320251 1 Pinion & crown wheel set 28/17 ratio
WG9231340002 4 Hex socket plug –
WG9012340011 2 Hub cover ejector pin –

Full axle catalog includes 6 sub-assemblies: Mid Axle Housing, Mid Axle Drive, Rear Axle Hub & Brake (standard), Rear Axle Housing, Rear Axle Drive, and Rear Axle Hub & Brake (ABS variant).

4. Front Axle System (~98 Parts, 2 Sub-Assemblies)

HOWO front axles are available in 7T and 9T load ratings with different spring distances (850mm / 900mm). Our catalog covers both the axle assembly and front wheel brake components.

4.1 Front Axle Assembly (7T & 9T)
Part No. Qty Part Name Specification
AZ9719410103 1 Front axle (7T) Spring distance 850mm
AZ9125411154 1 Front axle (7T) Spring distance 900mm
AZ9925410121 1 Front axle (9T) Spring distance 850mm
AZ9719410093 1 Front axle (9T) Spring distance 900mm
WG880410031 2 Knuckle pin –
AZ9112410055 1 Left knuckle –
AZ9112410056 1 Right knuckle –
AZ9719410005 1 Steering knuckle arm –
4.2 Front Wheel Brake
Part No. Qty Part Name Specification
AZ9112440001 2 Brake drum –
AZ9100440018 4 Brake shoe assembly –
WG9100440029 4 Brake lining (T-type) –
WG9112440006 2 Dust shield (with ABS) ABS-compatible

5. Cabin Assembly (~625 Parts, 27 Sub-Assemblies)

The HOWO cabin catalog is the most extensive section, covering everything from the bare cabin body to interior trim, seats, dashboard, glass, wipers, mirrors, HVAC, and suspension systems.

5.1 Cabin Body & Doors
Part No. Qty Part Name Specification
AZ1641900003 1 Cabin assembly (improved front suspension) Complete
AZ1641100003 1 Short cabin body with doors Improved front suspension
AZ1641180003 1 Standard cabin body New front panel
AZ1642210001 1 Left door assembly –
AZ1642210002 1 Right door assembly Mirrored to left
AZ1642210009 2 Door hinge assembly –
5.2 Dashboard, Seats & Interior
Part No. Qty Part Name Specification
AZ1644900001 1 Dashboard assembly –
AZ1644510001 1 Driver seat assembly –
AZ1644520001 1 Passenger seat assembly –
AZ1644300001 1 Interior trim assembly With rear window
AZ1644400001 1 Floor mat –
AZ1644200001 1 Sound insulation panel –
5.3 Glass, Wipers, Mirrors & HVAC
Part No. Qty Part Name Specification
AZ1644600001 1 Windshield glass assembly –
AZ1644700001 2 Wiper assembly –
AZ1644800001 2 Outer rearview mirror assembly –
AZ1645000001 1 Heater assembly HW series
AZ1645100001 1 Windshield washer assembly –

Full cabin catalog includes 27 sub-assemblies: Cabin Assembly, Cabin Body, Front Panel & Radiator Grille, Fenders, Door Accessories, Locks, Corner Windows, Sun Visor, General Parts, Dashboard, Driver Seat, Passenger Seat, Seat Belts, Interior Trim, Floor Mats, Sound Insulation, Glass, Wipers, Storage Box, Roof Hatch, Mirrors, Heater, Washer, Rear Fenders, Front Suspension, Rear Suspension, and Cabin Lifting Device.

Three Quality Tiers for Every Budget

We offer three quality levels to match your fleet’s maintenance strategy and budget requirements. All parts are inspected before shipment with detailed photos and videos provided.

Genuine OEM Parts
Premium Tier — 100% factory original
  • SINOTRUK genuine parts with factory packaging
  • Full warranty and traceability
  • Original part numbers (AZ / WG / VG series)
  • Recommended for critical engine & transmission components
OEM-Grade Parts
Mid Tier — same factory, different packaging
  • Manufactured by OEM-supplier factories
  • Same material & dimensional specs as genuine
  • Cost-effective for bulk fleet maintenance
  • Ideal for axle, brake, and cabin components
Reliable Aftermarket
Economy Tier — tested quality alternatives
  • Quality-tested aftermarket replacements
  • Significant cost savings for older fleets
  • Pre-shipment inspection with photos & videos
  • Suitable for non-critical & wear parts

Why Choose Archer Parts?

Exact Part Number Matching

Provide us with part numbers, VIN, chassis number, or engine nameplate — we cross-reference against the factory EPC catalog to guarantee correct matching.

Pre-Shipment Inspection

Every batch is inspected before shipping. You receive high-resolution photos and videos of your parts before they leave our warehouse.

Global Export Experience

We export to Africa, Middle East, South America, Southeast Asia, and Europe. We understand your local import regulations and shipping requirements.

Bulk & Mixed Orders

Order a single part or a full container. We handle mixed orders across all systems and quality tiers with consolidated shipping.

Technical Support

Our team provides installation guidance, torque specs, and troubleshooting support for all HOWO truck systems.

Fast Response

Quotes within 24 hours. Most orders ship within 3-7 days depending on availability and quantity.

How to Order

1
Send Part Numbers
Email or WhatsApp us your part numbers, VIN, or photos
2
Receive Quote
We confirm availability, quality tier & pricing within 24h
3
Inspection & Photos
Pre-shipment inspection with detailed photos & videos
4
Ship & Track
Consolidated shipping with full tracking to your destination

Frequently Asked Questions

Q: Which HOWO truck models are covered by this catalog?
A: This catalog covers SINOTRUK HOWO heavy-duty trucks equipped with the WD615 engine and HW19710 transmission. This includes HOWO 7-series and 8-series trucks (HOWO 371, HOWO 420, and similar models) used worldwide for construction, mining, and logistics.
Q: Can I order parts if I only have the truck’s VIN or chassis number?
A: Yes. Our team can cross-reference your VIN, chassis number, or engine nameplate against the factory EPC (Electronic Parts Catalog) to identify the exact part numbers you need. Just send us what you have.
Q: What’s the difference between Genuine OEM, OEM-Grade, and Aftermarket parts?
A: Genuine OEM parts come in original SINOTRUK packaging with full warranty. OEM-Grade parts are made by the same supplier factories but without the brand packaging — same quality at a lower price. Aftermarket parts are quality-tested alternatives from third-party manufacturers, offering the best value for non-critical and wear components.
Q: Do you provide pre-shipment inspection photos?
A: Yes. Every order is inspected before shipment. We provide high-resolution photos and videos of all parts, including packaging, labels, and part numbers, so you can verify everything before it ships.
Q: What’s the minimum order quantity (MOQ)?
A: There is no fixed MOQ. You can order a single part or a full container. For small orders, we recommend consolidating multiple parts to optimize shipping costs. Mixed orders across different systems and quality tiers are welcome.
Q: How long does it take to receive a quote?
A: We typically respond within 24 hours (business days). For complex or large orders requiring multiple suppliers, it may take up to 48 hours. Quotes include unit pricing, availability, lead time, and estimated shipping costs.
