LOVOL Wheel Loader Spare Parts

LOVOL Wheel Loader Spare Parts — Engine, Transmission, Hydraulic & Filters

One-stop supply for LOVOL wheel loader spare parts covering all major systems: Weichai WD10/WP10 engine components (pistons, liners, crankshafts, turbochargers, cylinder heads, overhaul kits), transmission system (torque converter, gearbox, clutches, seals), drive axle (front/rear axle assembly, differential, final drive, universal joint), hydraulic system (working pump, steering pump, multi-way valve, lift/tilt/steering cylinders, seal kits), brake system (disc/drum brake, brake caliper, master cylinder, accumulator), electrical system (alternators, starters, ECU, wiring harness, sensors), cab & body parts, bucket & attachments (edges, teeth, pins, bushings), tires & wheels,filter.

LOVOL Spare Parts lovol engine parts, lovol filter, lovol parts, lovol parts catalog, lovol parts suppliers, lovol spare parts

Contact Us for Pricing

Interested in this product? Contact us now for detailed pricing and product information.

Product Details

LOVOL Wheel Loader Spare PartsFull-System Genuine & OEM Supply
LOVOL Wheel Loader Spare Parts — Engine · Transmission · Hydraulic · Filters

Complete spare parts supply for the full LOVOL wheel loader range from FL935 to FL988. We cover eight major systems — Weichai WD10/WP10 engine, torque converter & gearbox, drive axle, hydraulic system, brake system, electrical, cab & body, and all filter elements. Each part is cross-referenced against your machine’s engine serial number and VIN for guaranteed fitment. Three quality tiers: Genuine LOVOL OEM, and OEM-grade options to match your budget.

Engine Transmission Drive Axle Hydraulic Brake Filters

8
Major Systems
7+
Loader Models
500+
Part Numbers
3
Quality Tiers
24h
Quote Turnaround
100%
Pre-Ship Inspection

Filter Elements — 5 Types, 16+ Verified Part Numbers

▶ Hydraulic Return Oil Filter
9D650-58A030000A0
9F850-58A050000A0
9G667-58C020000A0
Fits FL935 / FL936 / FL955 / FL956 / FL958 hydraulic tank return line.

▶ Hydraulic Suction / Working Oil Filter
9F550-58A030000B0
9F550-58A040200A0
9F662-58A030000A0
Installed at hydraulic pump suction port — protects pump from contamination. Fits FL935-FL988.

▶ Pilot Filter
9G661-59A050000A0
Fine-filtration for pilot control circuit — protects sensitive servo valves on FL955/FL956/FL958/FL966/FL988.

▶ Air Filter Assembly / Element
9H010-68A201102A0
9F580-58A040000A0
Main engine intake air filter. Two-stage element design (outer primary + inner safety). Fits FL935-FL988 series.

▶ Fuel / Diesel Filter
9F569-31A010102A0
9D650-31A030000B0-01
9D650-31A030200A0
Common-rail fuel system fine filter. Cross-reference: fits Weichai WD10 / WP10 engines on FL955-FL988.

▶ Weichai WD10 / WP10 Engine-Specific Filters
Filter Type Part Numbers
Engine Oil Filter T75004245 / 1000428205
Fuel Coarse Filter (w/ Water Separator) 612600081334 / 1000422382
Fuel Fine Filter 612600081335
These are direct-fit filters for Weichai WD10 / WP10 engines installed in LOVOL FL955, FL956, FL958, FL966, and FL988 wheel loaders.

Weichai WD10 / WP10 Engine System Parts
Cylinder Block & Head
  • Cylinder Head Assembly
  • Head Gasket Kit
  • Cylinder Block
  • Valve Cover
  • Rocker Arm Assembly
  • Intake & Exhaust Valves
Cranktrain & Pistons
  • Crankshaft Assembly
  • Piston Kit (w/ Rings & Pin)
  • Connecting Rod
  • Main Bearing Set
  • Thrust Washer
  • Flywheel & Ring Gear
Turbo & Cooling
  • Turbocharger Assembly
  • Water Pump
  • Radiator Core
  • Fan Drive & Belt
  • Thermostat
  • Intercooler
Fuel Injection System
  • Fuel Injection Pump
  • Injector Assembly
  • High-Pressure Pipe Set
  • Fuel Feed Pump
  • Injection Nozzle
  • Common Rail Assembly
Lubrication System
  • Oil Pump Assembly
  • Oil Cooler Core
  • Oil Pressure Sensor
  • Oil Pan / Sump
  • Dipstick & Guide Tube
  • Breather / PCV Valve
Overhaul Kits
  • Complete Engine Overhaul Kit
  • Top-End Gasket Set
  • Bottom-End Gasket Set
  • Timing Gear Kit
  • Camshaft Assembly
  • Cylinder Liner Kit

Transmission System — Torque Converter & Gearbox
Torque Converter
  • Torque Converter Assembly
  • Pump Wheel / Turbine Wheel
  • Stator / Guide Wheel
  • Lock-Up Clutch Kit
  • Input / Output Shaft
  • Flex Plate / Drive Plate
Gearbox Assembly
  • Gearbox Housing
  • Gear Set (FWD 1-4 / REV 1-3)
  • Shifting Fork / Rail
  • Selector Valve / Solenoid
  • Shift Cable / Linkage
  • Gear Position Sensor
Clutch & Seals
  • Clutch Disc / Friction Plate
  • Clutch Pressure Plate
  • Release Bearing
  • Oil Seal Kit (Complete)
  • Gasket Set
  • Transmission Oil Pump
Driveshaft
  • Front Driveshaft Assembly
  • Rear Driveshaft Assembly
  • Universal Joint Cross
  • Center Support Bearing
  • Slip Yoke / Spline
  • Flange Yoke

Drive Axle System — Front & Rear
Axle Assembly
  • Front Drive Axle Assembly
  • Rear Drive Axle Assembly
  • Axle Housing
  • Steering Knuckle
  • Steering King Pin Kit
  • Axle Shaft (Half Shaft)
Differential & Final Drive
  • Differential Assembly
  • Ring & Pinion Gear Set
  • Differential Bearing Kit
  • Final Drive / Hub Reduction
  • Planetary Gear Set
  • Wheel Hub Assembly
Seals & Bearings
  • Axle Oil Seal Kit
  • Pinion Seal
  • Wheel Hub Seal
  • Wheel Bearing Set
  • Pinion Bearing Set
  • Axle Gasket Set

Hydraulic System — Working & Steering
Hydraulic Pumps
  • Working Hydraulic Pump
  • Steering Pump
  • Pilot Pump
  • Pump Drive Gear
  • Pump Shaft Seal Kit
  • Suction Strainer
Control Valves
  • Multi-Way Directional Valve
  • Pilot Control Valve
  • Steering Priority Valve
  • Relief Valve (Main)
  • Overload Relief Valve
  • Solenoid Valve Block
Hydraulic Cylinders
  • Lift Cylinder Assembly
  • Tilt Cylinder Assembly
  • Steering Cylinder
  • Cylinder Seal Kit
  • Piston Rod / Gland
  • Cylinder Tube
Hoses & Fittings
  • High-Pressure Hose Set
  • Return Hose Set
  • Suction Hose
  • Steel Tube / Pipe
  • Hydraulic Quick Coupler
  • O-Ring / Bonded Seal Set
Hydraulic Tank
  • Hydraulic Oil Tank
  • Tank Cap / Breather
  • Oil Level Gauge
  • Return Filter Housing
  • Suction Filter Housing
  • Tank Mounting Hardware

Brake System
Service Brake
  • Brake Caliper Assembly
  • Brake Disc / Drum
  • Brake Pad / Lining Set
  • Brake Shoe Kit
  • Return Spring Kit
  • Brake Piston Seal Kit
Parking Brake
  • Parking Brake Assembly
  • Brake Cable
  • Parking Brake Drum
  • Parking Brake Shoe
  • Parking Brake Lever
  • Actuator / Spring Chamber
Hydraulic / Air Boost
  • Brake Master Cylinder
  • Brake Booster / Accumulator
  • Air Compressor (if equipped)
  • Brake Valve / Treadle Valve
  • Brake Fluid Reservoir
  • Brake Pipe / Hose Kit

Electrical System
Charging & Starting
  • Alternator (28V / 14V)
  • Starter Motor Assembly
  • Starter Solenoid / Relay
  • Battery / Terminal
  • Ignition Switch
  • Master Disconnect Switch
Sensors & Controls
  • ECU / Engine Controller
  • Throttle Position Sensor
  • Temperature Sensor Set
  • Pressure Sensor Set
  • Speed Sensor
  • Fuel Level Sensor
Wiring & Lights
  • Main Wiring Harness
  • Engine Harness
  • Work Light Assembly
  • Instrument Panel / Cluster
  • Warning Light / Buzzer
  • Fuse & Relay Box

Cab & Body Parts | Bucket & Attachments
Cab & Body
  • Cab Glass (Front / Side / Rear)
  • Door Lock & Handle Set
  • Seat Assembly
  • Hood / Engine Cover
  • Counterweight
  • Cab Mount / Rubber Pad
  • Heater / AC Unit
  • Windshield Wiper Motor & Arm
  • Side Mirror
  • Mudguard / Fender
Bucket & Attachments
  • Bucket Assembly (1.7-5.0 m³)
  • Bucket Cutting Edge / Lip
  • Bucket Tooth / Adapter
  • Tooth Pin & Retainer
  • Side Cutter / Wear Plate
  • Z-Bar Linkage / Pins
  • Lift Arm / Boom Assembly
  • Boom Pin & Bushing Kit
  • Quick Coupler (if equipped)
  • Fork / Log Grapple Attachment

Tires & Wheels
Tires
  • 17.5-25 L3/E3 (FL935/FL936)
  • 20.5-25 L3/E3 (FL955/FL956)
  • 23.5-25 L3/E3 (FL958/FL966)
  • 26.5-25 L3/E3 (FL988)
  • Inner Tube & Flap
  • Solid Tire Option
Wheels
  • Wheel Rim Assembly
  • Wheel Nut / Stud Set
  • Wheel Hub Cover
  • Wheel Spacer / Adapter
  • Valve Stem / Core
  • Wheel Clamp Ring (if applicable)

LOVOL Wheel Loader Models Covered
Model Operating Weight Bucket Capacity Engine Tire Size
FL935 ~10,500 kg 1.7 – 2.0 m³ Weichai WD10 17.5-25
FL936 ~11,000 kg 1.8 – 2.2 m³ Weichai WD10 17.5-25
FL955 ~16,500 kg 2.8 – 3.5 m³ Weichai WP10 20.5-25
FL956 ~17,500 kg 3.0 – 3.8 m³ Weichai WP10 20.5-25
FL958 ~19,000 kg 3.5 – 4.5 m³ Weichai WP10 23.5-25
FL966 ~22,000 kg 4.0 – 5.0 m³ Weichai WP10 23.5-25
FL988 ~28,000 kg 5.0 – 6.0 m³ Weichai WP10 26.5-25

Why Choose Archer Parts for LOVOL Wheel Loader Spare Parts
Serial Number Cross-Reference
We match every part against your machine’s engine serial number and VIN to eliminate mis-shipment. LOVOL uses multiple engine configurations across model years — especially Weichai WD10 vs WP10 — and we verify fitment before quoting.
Three Quality Options
Genuine LOVOL OEM (branded packaging), Genuine OEM (neutral packaging — same factory, same line), and OEM-Grade Replacement (Tier-1 supplier, same spec, best value). Same filtration performance — different packaging and brand authorization cost.
Pre-Shipment Inspection
Every order is inspected and photographed before packing. Filters are individually sealed and boxed. We send inspection photos before shipping so you know exactly what you’re getting.

Three Quality Tiers — Choose What Fits Your Budget
Quality Tier Source & Quality Packaging Best For
Genuine OEM (Branded) Direct from LOVOL factory — same parts installed on new machines. Full traceability and factory QC. LOVOL branded packaging w/ logo & anti-counterfeit Critical engine/transmission parts, warranty repairs, dealer resale
Genuine OEM (Neutral) Same factory, same production line as branded. Neutral packaging eliminates brand licensing cost — best value for fleet operators. Neutral packaging (no brand logo) Fleet operators, cost-sensitive projects, non-warranty repairs
OEM-Grade Replacement Manufactured to LOVOL OEM specifications by certified Tier-1 suppliers. Same performance as genuine at a lower cost. Neutral packaging Routine maintenance, filters, brake pads, consumables

How to Order LOVOL Wheel Loader Spare Parts
1
Send Machine Details
Share your LOVOL model, engine serial number (or VIN), part numbers if available, and photos of worn parts.
2
Receive Quotation
We confirm part numbers against LOVOL’s EPC database and send a detailed quote within 24 hours — with three quality/price options.
3
Inspect & Ship
You receive inspection photos before payment. After approval, we pack and ship by air or sea — DDP available to your nearest port.

Need LOVOL Wheel Loader Spare Parts? Get a Quote Today

Send us your part numbers, engine serial number, or photos of worn parts. We’ll confirm the exact part numbers and provide a detailed quote within 24 hours — with inspection photos before shipping.

JINAN ARCHER TRADE CO., LTD | archerparts.com | archermach.com
